Electric Single Girder Overhead Cranes
The electric single-girder overhead crane is a compact and flexible electric lifting device. Its suspended design allows for direct installation on factory roof structures, eliminating the need for ground space or additional track supports. It features stable performance, easy maintenance, and smooth operation. Equipped with an advanced drive and control system, it offers various working modes to suit different industrial production scenarios, particularly suitable for factory environments with limited height and space.
Product Description
The electric single-girder overhead crane is an electric lifting device adaptable to various industrial scenarios. Key features include:
Installation Method
Utilizing a suspended design (such as the LX electric single-girder overhead crane), it can be directly installed on the existing factory roof structure without the need for track supports, saving factory space. It can also be used in specific areas of the factory, offering flexible and convenient installation.
Core Application
It uses an electric drive mechanism to move objects up and down, enabling material handling operations in various industrial scenarios, suitable for locations with limited height and space.
Drive Unit
Equipped with a squirrel-cage motor, hardened gear reducer, and self-adjusting disc brake. It offers convenient operation, requires no maintenance, and can be operated wirelessly from the ground or remotely.
Performance Configuration
IP55 protection rating, F-class insulation, high-strength galvanized steel wire rope, and variable frequency speed control for both trolley and crane, ensuring smooth operation. It also features an anti-sway optimization design, enhancing lifting safety and accuracy.
Structural Composition
Optimized design with a compact structure, consisting of a hoisting mechanism, single main beam, end beams, and electrical control system. It is lightweight, has low wheel pressure, and a compact size, making it suitable for factory environments with limited height.
Drive and Control
Employs an electric drive mechanism, using an electric motor to drive the hoisting mechanism. It is equipped with an advanced control system and multiple safety protection devices to ensure operational safety.
Working Mode
Different working modes can be selected according to actual needs, including hoisting and variable frequency speed control, meeting the requirements of different occasions and adapting to diverse lifting needs.
Maintenance Characteristics
Compact structure, lightweight, and simple maintenance process, reducing unnecessary trouble, effectively lowering maintenance costs and repair time, and improving equipment utilization efficiency.
Product Feature
Flexible Installation
Can be directly installed on the roof structure of existing factory buildings without the need for track supports, saving factory space. It can be used in portions of a factory as needed, adapting to various factory layouts.
High-Quality Drive
Employs a squirrel-cage motor, hardened gear reducer, and self-adjusting disc brake, featuring a maintenance-free operation mode, supporting wireless ground operation and wireless remote control, making operation convenient and efficient.
Excellent Performance
IP55 protection rating, F-class insulation, equipped with high-strength galvanized steel wire rope, frequency conversion speed regulation for both trolley and crane, ensuring smooth operation, and featuring an optimized anti-sway design for safety and precision.
Optimized Structure
Optimized design, lightweight, low wheel pressure, and compact size, consisting of a lifting mechanism, single main beam, end beams, and electrical control system, suitable for locations with limited height.
Suspended Design
Utilizing a suspended installation, it can be fixed to the ceiling, eliminating the need for floor space and maximizing the use of upper factory space.
Reliable Electric Drive
The lifting mechanism is driven by an electric motor, enabling the vertical movement of heavy objects. Equipped with an advanced control system and multiple safety protection devices, it ensures safe and stable operation.
Diverse Working Modes
Different working modes (including hoisting, frequency conversion speed regulation, etc.) can be selected according to actual needs to meet the requirements of various applications.
Easy Maintenance
The compact structure and lightweight design simplify maintenance, reducing unnecessary trouble, maintenance costs, and repair time.
Wheel Assembly Materials
Main Materials
1. Single Main Beam and End Beams: The core is made of high-quality carbon structural steel (mostly Q235B or Q355B), welded and optimized in design, possessing high strength and rigidity while maintaining light weight and low wheel pressure, allowing for stable bearing of lifting loads.
2. Lifting Mechanism: The wire rope is made of high-strength galvanized material, featuring wear resistance, corrosion resistance, and high load-bearing capacity; core load-bearing components such as the hook are made of high-strength alloy materials to ensure lifting safety.
3. Drive and Electrical Components: The squirrel-cage motor and hardened gear reducer are made of high-quality steel and wear-resistant alloy materials to ensure stable drive and long service life; electrical control system components (controllers, cables, etc.) are made of high-quality electrical materials with IP55 protection rating and F-class insulation, suitable for industrial environments, ensuring precise and reliable control.
4. Auxiliary Components: The self-adjusting disc brake uses high-temperature resistant and wear-resistant alloy materials to ensure stable braking performance; suspension brackets, connectors, etc., are made of high-strength steel with rust-proof surface treatment to improve corrosion resistance and suitability for long-term suspended installation.
